TECHNICAL SPECIFICATIONS

Machine Sizes	23 X 23	27 X 27	30 X 30
Diemension	L54'' X W36'' X H42''	L54'' X W40'' X H42''	L54'' X W43'' X H42''
No.of.Cutter	10Nos	10Nos	10Nos
4Line Creasing	4Nos	4Nos	4Nos
Minimum Gap	16mm	16mm	16mm
Minimum GSM	45 GSM	45 GSM	45 GSM
Maximum GSM	400 GSM	400 GSM	400 GSM
Nett Weight	250Kgs	280 kgs	300Kgs
Power	0.5 Hp / 1 phase	0.5 Hp / 1 phase	0.5 Hp / 1 phase
Speed	Variable Speed	Variable Speed	Variable Speed

Salient Features:

Simple Operating Training gives Mass production

Designed to Portable and Compact

Suitable for Micro perforation, Creasing & Sticker half cutting

Additional Spine Creasing by Male & Female in Min 3 mins.

Friction Feeding for all kind of Papers & Boards in any GSM can be adjusted according to stock thickness.

Rotary cutter can be adjusted individual and precisely.

Provided Micro Adjustment side Lay.

Max Paper Size 18''*23''& Min 4''*4''

Low Power Consumption
